McIntyre Colossus Macchina per la fusione di lingotti

High-Capacity Industrial Ingot Casting System

At JMC Recycling, we design and manufacture high-performance McIntyre ingot casting machines built for durability, efficiency and real-world production environments.

Developed in our own foundry and proven in demanding applications worldwide, the McIntyre Colossus is our largest and highest-capacity casting system, engineered for continuous, large-scale ingot production.

Maximum Output. Proven Reliability.

The Colossus has been designed to deliver trouble-free alloy production at scale, making it ideal for high-volume smelting and processing operations.

Unlike standard systems, this machine is built from real foundry experience. We don’t just design these machines — we’ve used them ourselves — ensuring reliability, consistency and long-term performance in demanding environments.

Engineered for Large-Scale Production

The system uses a controlled pouring wheel to deliver molten metal into moulds with precision, ensuring:

• Consistent ingot weight and shape
• Reduced dross formation
• High throughput with minimal interruption

Advanced cooling combines air cooling fans and water spray systems, maintaining production efficiency even at high output levels.

Caratteristiche principali

• Heavy-duty, high-capacity ingot casting system
• Designed for continuous industrial production
• Controlled pouring wheel system
• Combined air and water cooling for efficiency
• Automatic ingot knockout system
• Robust, fully welded steel construction
• Custom mould design available (including embossed branding)
• Full installation, training and aftersales support available

Material Capability

Suitable for processing:
• Aluminium
• Copper
• Brass
• Other non-ferrous alloys

Typically configured for long bar ingots, with custom mould designs available to suit your exact requirements.

Specifiche Tecniche Tipiche

(Solo indicazione – soggetta a configurazione)
• Production rate: approx. 11–12 tonnes per hour
• Number of moulds: approx. 260
• Ingot type: approx. 13 kg long bar ingots
• Mould material: ductile cast iron
• Pouring system: pouring wheel
• Cooling system: air cooling fans + water spray nozzles
• Drive motor: approx. 2.2 kW (3 phase)
• Speed control: electronic inverter
• Maximum water consumption: approx. 120 L/min at 3 bar
• Construction: fully welded heavy-duty steel frame
• Approx. weight: up to 24,000 kg

Costruito intorno alla tua operatività

Every Colossus system is engineered to suit your process, including:
• Ingot size, weight and mould configuration
• Throughput and production targets
• Cooling systems and environmental controls
• Integration with furnaces and handling systems
• Electrical setup for international installations

Global Installation & Support

The Colossus has been supplied to major international operations, with full commissioning, training and support packages available worldwide — ensuring your system is installed and operating at peak performance from day one.

The Ultimate Casting Solution

For operations requiring maximum output, consistency and reliability, the McIntyre Colossus delivers industry-leading performance at scale.

Contact us today to discuss your casting requirements
